Building a DC Motor – Top 5 Student Mistakes

Is your motor all powered up, but not spinning? Don’t worry! In this article, Experimental Physicist and Matrix Physics guru Tom Dixon shares the top 5 student mistakes when building electric motors.

Tom explains the theory, describes the problem and then provides simple solutions so that you can motor through your next HSC Physics Practical Assessment.


Top 5 Student Mistakes When Building Electric Motors Tom and his motor

A fully assembled and functioning motor


Common Mistake 1. Poor commutator brush connection

The Idea:

The connection between the commutator and brushes allows current to be supplied to the motor, and for that current to reverse direction every half turn.

The Problem:

Most students will use bare wires as their brushes. If the wires are not pressing strongly enough against the commutator, they will not be in electrical contact for the entire rotation!

Our Solutions:

Connect an ammeter in series with the motor and rotate the coil 360 degrees – check if current is flowing throughout the rotation. There should be electrical connection almost constantly.

Using a rigid wire will ensure that they are not pushed away from the commutator during rotation. In addition, using the middle of the bare-part of the wire (not the tip) for the contact can make for a smoother connection.



Common Mistake 2. Poor commutator coil connection

The idea:

In the rotor, each side of the commutator is attached to one end of the coil. Power is connected to the commutator (via the brushes) and then into the coil.

The Problem:

Students may not have properly stripped the insulation from the edges of their wire; the commutator might not be connected to the underlying coil wires!

Our Solutions:

Check the connection between the two ends of the coil before constructing the commutator (you can use a multimeter in ‘beep mode’). You can improve the connection by wrapping the bare copper ends in aluminium foil before constructing the commutator.



Common Mistake 3. High rotational friction

The Idea:

The motor generates a torque that rotates the rotor. Sources of friction in the motor will oppose this motion, reducing the net torque slightly.

The Problem:

In some motor constructions, the frictional torque is greater than the motor torque! This will result in a motor that doesn’t move, or only makes it a few turns before stopping.

The Solution:

Reducing friction is necessary – check the rotor mounting points and see if you can make the connection smoother. Also consider the connection between the brushes and commutator – if they are pressing too hard, this will be another source of friction.

It is always a good idea to spin the motor by hand, to see if there are any points in its rotation where it catches / experiences a lot of resistance.



Common Mistake 4. Wear of the commutator.

The Idea:

Due to the relative motion between commutator and brushes, there is quite a bit of friction. In conventional motors, this wears away the commutator brushes, which are easy to replace.

The Problem:

If students build the commutator out of a weak material like aluminium foil, it will likely wear away first due to friction between the brush-wires and the foil. This can lead to poorer electrical contact and the motor not working!

Our Solutions:

In a pinch, you can always add more foil to each side of the commutator, if you make sure that the separate sides still don’t touch. A better long-term solution is to use thin, malleable sheet metal like copper sheet, which you can get from an arts and crafts store – these are far likely to last when compared to aluminium foil!

Building a DC Motor - Top 5 Student Mistakes-tom-and-motor-banner


Common Mistake 5. Rotor Axis misalignment

The Idea:

The rotor is supported in two places by the rotor mounts – usually at either ends of the rotor.

The Problem:

If the two rotor mounts are slightly misaligned, the rotor may jam, or experience a high amount of friction. Unfortunately, it is difficult to know if the alignment of the rotor mounts is at the best position until you turn on the motor!

Our Solutions:

One possible solution is to leave one rotor mount loose and able to be re-positioned. Then, you can re-position the mount as the motor is running, moving it around until you find the best configuration.
